CANWAY at the International Suppliers Fair (IZB) 2018

CANWAY presents its innovative solutions from the fields of bus system technology, current measurement technology and HiL test rig technology at the international supplier fair 2018.

We look forward to welcoming you to our stand for a personal discussion.

All information at a glance:
International Supplier Fair in Wolfsburg (IZB)
16.10.-18.10.2018
Wolfsburg (DE) Allerpark
Hall 3, Booth 3310

Software release V1.6.3.0 CANnect configuration software CW-921





The latest update for the CW-921 configuration software for the CANnect gateway is now available.
New features include:

• Records function: Dynamic circular buffer for incoming CAN messages
• Change event: Specific message forwarding if a value changes
• Data fill result: Additional verification view to improve restbus simulation
• Item edit: Improved security through locking low-level settings
• Usability improvements: Improved validation options, new module tab, move items by drag-and-drop operation and much more…

CAN FD extension module for the high performance CANnect gateway

The new extension module now enables the proven fieldbus gateway CANnect to access CAN FD networks (ISO 11898 and non-ISO). Amongst other features the high performance extension offers four CAN FD interfaces, each with flexibly adjustable data transmission rates up to 8 MBit/s. Both Fibex and ARXML databases can be used for description files. Furthermore, there are numerous channels available for measurement and control tasks: Analog-digital converter, digital-analog converter and digital outputs.

CW-401 The intelligent current clamp meter with CAN-interface

The CW-401 current clamp meter with a measurement range of ±30 A (further measurement ranges on request) is well-suited for an ambient temperature of -40 °C to +120 °C. Here it achieves  a relative accuracy of 1 % by the help of a temperature compensation. Thanks to its slewable measuring head as well as to its compact and robust design it is possible to take measurements in rugged environments  or hard-to-reach places. Beside the current value the temperature can also be read out easily via CAN-connection. So that the received data can be processed in established tool chains.

CANnect High Performance Gateway for CAN & LIN - Software Release

With the arrival of the new software version 1.3.4.0, the Bus-Gateway CANnect has been further improved and equipped with several new features. In addition to the description files CANdb, ARXML and LDF (LIN) the A2L-format (XCP) is now fully supported. XCP is commonly used for an easy access to internal ECU variables. Another innovation is the bidirectional communication of CAN/LIN/XCP messages via Ethernet. The linking  of various networks can be comfortably created  by drag&drop. Even a comprehensive rest-bus simulation can be performed.

PRECISION MEASUREMENT OF NO-LOAD AND WORKING CURRENTS WITH THE CW-425

The CW-425 facilitates measuring working currents in the 0 µA to 30 A range. The wide measurement range is made possible by two different measuring shunts, which thanks to a switching delay of less than 2 µS ensures it is possible to switch from one to the other virtually seamlessly.  The measured value of the CW-425 is issued via CAN bus; as a consequence, it can easily be integrated in different measuring chains. The field of application of the CW-425 is, for example, automated measurement of no-load and working currents of control units on HiL test benches.
